主要特点
1.高强度绿色板栅合金:比银离子板栅合金的耐腐蚀性更高,更稳定、寿命更长;
2.产品结构采用铸焊、壁焊接技术,超大电流放电性能优越;
3.消费型设计,经济适用;
4.童车、灯具、均衡器等采用循环工艺,循环深放电寿命长。
规格型号参数表
电池型号 |
额定
电压
(V) |
额定
容量
C20 |
外形尺寸(mm) |
端子 |
标准
重量
(kg) |
长度 |
宽度 |
高度 |
总高 |
说明
书型号 |
TNE6-3.2 |
6 |
3.2 |
70 |
47 |
100 |
106 |
T1/T2 |
0.68 |
TNE6-4.5 |
6 |
4.5 |
70 |
47 |
100 |
106 |
T1/T2 |
0.75 |
TNE6-7.0 |
6 |
7 |
151 |
35 |
93 |
99 |
T1/T2 |
1.1 |
TNE12-4.5 |
12 |
4.5 |
90 |
70 |
101 |
107 |
T1/T2 |
1.48 |
TNE12-5.0 |
12 |
5 |
90 |
70 |
101 |
107 |
T1/T2 |
1.6 |
TNE12-5.4 |
12 |
5.4 |
90 |
70 |
101 |
107 |
T1/T2 |
1.65 |
TNE12-6.0 |
12 |
6 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
1.9 |
TNE12-6.5 |
12 |
6.5 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
2.06 |
TNE12-7.0 |
12 |
7 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
2.18 |
TNE12-8.0 |
12 |
8 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
2.57 |
TNE12-8.0B |
12 |
8 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
2.35 |
TNE12-8.5 |
12 |
8.5 |
151 |
65.5 |
93.5 |
99.5 |
T1/T2 |
2.45 |
TNE12-10 |
12 |
10 |
151 |
99.5 |
95.5 |
101.5 |
T1/T2 |
3.25 |
TNE12-12 |
12 |
12 |
151 |
99.5 |
95.5 |
101.5 |
T1/T2 |
4.05 |
TNE12-12B |
12 |
12 |
151 |
99.5 |
95.5 |
101.5 |
T1/T2 |
3.6 |
TNE12-40 |
12 |
40 |
195 |
130 |
157.5 |
162 |
I1 |
11.1 |
TNE12-45 |
12 |
45 |
198.5 |
166 |
169.5 |
169.5 |
I3 |
13.5 |
TNE12-60B |
12 |
60 |
229 |
138.5 |
211 |
216 |
I3 |
16.5 |
